Fast steering mirror (FSM) platforms are used in imaging, astronomy, laser machining, free space communication, etc. PI's FSMs are based on high-speed solid-state piezoelectric drives & frictionless flexure guides. They provide faster response than galvo-scanners and voice-coil drives and can be used in both static and highly dynamic operation (e.g. scanning, tracking, drift and vibration cancellation).

We also offer standard and custom voice-coil FSMs, optimized for larger angles. Advantages of PI fast steering mirrors are: coplanar multiaxis motion due to parallel kinematics design, fastest response (sub-millisecond), high resolution (up to nanoradian range), long travel ranges.

More Information...

Download the Steering Mirror Catalog





Single-Axis Platforms / Shifters


S-303 Compact Piezo Phase Shifters, with Capacitive Feedback Option, Ultra Fast
Product Image - High-Speed Piezo Phase Shifters with Direct Metrology Option
  • Ultra High Dynamics (to Microsec Response): 25 kHz Resonant Frequency
  • <0.1 Nanometers Resolution
  • Optional Capacitive Feedback for Highest Linearity and Stability
  • Invar Option for Highest Thermal Stability
  • Aperture with Open-Loop Versions
  • 3 Micron Travel Range
  • Compact: Only 30mm Diameter x 10mm Height
Piezo Phase Shifter Datasheet





S-224 Single Axis High-Speed Piezo Steering Mirror / Mini Mirror Tilter
Product Image - High-Speed Miniature iezo Mirror Tilter
  • Sub-microradian Resolution
  • Very Fast: 10 kHz Resonant Frequency: Sub-Millisecond Response
  • To 4.4 milliradian Optical Beam Deflection
  • Closed-Loop Versions for Higher Accuracy & Linearity
  • Includes BK7 Mirror
  • Zero Friction Flexure Guiding System
Piezo Steering Mirror Datasheet




Multi-Axis FSM /Tip/Tilt Platforms


S-330 FSM High-Speed Piezo Tip/Tilt Platforms
Product Image - High-Speed Piezo Tip/Tilt Platforms
  • Common Pivot Point = Fixed Orthogonal Axes
  • Up to 20 milliradian Optical Beam Deflection
  • Up to 20 nanoradian Resolution
  • For Optics to 2" θ
  • Closed-Loop Versions for Higher Accuracy & Linearity
  • Differential Design for Excellent Temperature Stability
  • Zero Friction Flexure Guides
  • Single-Moving-Platform, Parallel-Kinematics Design: Equal Dynamics for all Axes, Better Linearity & Temperature Stability
Back to TopPiezo Steering Mirror Datasheet





S-335 Fast Steering Mirror w/ Ultra-Long-Range Piezo Drive (70 milliradian Deflection)
Product Image - Ultra-Long-Range Piezo Tip/Tilt Mirror
  • Optical Deflection to 100 milliradian (∼6°)
  • 2 kHz Resonant Frequency
  • Closed-Loop Version for Higher Linearity
  • For Mirrors up to 25mm (1") Diameter
  • 2 Fixed Orthogonal Axes with a Common Pivot Point
  • Sensor Configuration for Excellent Temperature Stability
  • Zero Friction Flexure Guides
Piezo Steering Mirror Datasheet





S-340 Fast Steering Mirror / High-Speed Piezo Tip/Tilt Platforms
Product Image - High-Speed Piezo Tip/Tilt Platforms
  • Fixed Orthogonal Axes with a Common Pivot Point
  • 4 milliradian Optical Beam Deflection
  • For Mirrors to 100 mm θ
  • Sub-microradian Resolution
  • Closed-Loop Versions for Higher Accuracy & Linearity
  • Differential Design for Excellent Temperature Stability
  • Zero Friction Flexure Guides
  • Single-Moving-Platform, Parallel-Kinematics Design: Equal Dynamics for all Axes, Better Linearity & Temperature Stability
Back to Top Piezo Steering Mirror Platform Datasheet




Z/Tip/Tilt Platforms (with Aperture)


S-310 and S-316 Fast Steering Mirror Platform / Piezo Tip/Tilt Platforms and Z Positioners w/Aperture
Product Image - High-Speed Multi-Axis Tip/Tilt Platforms and Z Positioners
  • Single-Moving-Platform, Parallel-Kinematics Design : Equal Dynamics for all Axes, Better Linearity & Temperature Stability
  • 10 mm Aperture
  • Tripod Design Allows Tip/Tilt and Z Piston Motion
  • Up to 2.4 milliradian Optical Beam Deflection
  • 12 Microns Piston Movement
  • Closed-Loop Versions for Higher Accuracy & Linearity
  • For Optics, Mirrors or Other Components
  • Zero Friction Guiding Mechanism
Piezo Tip/Tilt Platform Datasheet





S-325 Fast Steering Mirror, Piezo Tip/Tilt Platform & Z Positioner
Product Image - High-Speed Piezo Tip/Tilt Platform and Z Positioner
  • Piezo Tripod Design Allows Z Motion and Tilt
  • 10 milliradian Optical Beam Deflection
  • Z-Piston Movement to 30 Micrometers
  • Closed-Loop Option for Higher Linearity
  • For Optics to 25 mm (1 inch) Diameter
  • Zero Backlash /Zero-Friction Flexure Guides Single-Moving-Platform, Parallel-Kinematics Design: Equal Dynamics for all Axes, Better Linearity & Temperature Stability
Back to Top Piezo Steering Mirror Platform Datasheet




Large Z/Tip/Tilt Stages (with aperture)
Large Tip/Tilt Mirror for Astronomy Applications
